Our projects

Surex Surveyors works on large and small infrastructure projects across the globe.

Building tomorrow's cities

We take pride in the role we play in building the infrastructure for the cities of the future – infrastructure that will be used for generations to come. This includes tunnels, roads, railways, buildings, bridges and drainage networks.

Recent work

Below you’ll find examples of our recent work.

The Rozelle Interchange (West Connex 3b)

The Rozelle Interchange (West Connex 3b) project connects the extended M4 and the new M5 to the Anzac Bridge and Victoria Road in Sydney. The underground motorway is excavated by up to 20 roadheaders and is the most complicated network of tunnels constructed anywhere in Australia.

Surex is currently providing all the surveying required for excavation of this ground-breaking mega project. This includes calculation of all the tunnel profiles and ground support, maintaining the roadheader and bolter guidance systems, monitoring and final lining.

Rozelle Interchange tunnels
Rozelle Interchange network

Cross River Rail

Cross River Rail is a new 10.2 kilometre rail line from Dutton Park to Bowen Hills, which includes 5.9 kilometres of twin tunnels under the Brisbane River and CBD.

Surex has completed the project control and is currently engaged in providing all the tunnelling and rail survey requirements. This includes guiding the Tunnel Boring Machines, roadheader excavation for underground stations and tunnels, concrete lining, monitoring, rail installation and final fit out.

Cross River Rail TBM breakthrough

Sydney Metro Stage 1 & 2

West Rail Tunnel is Stage 1 of Sydney Metro. The project used four Tunnel Boring Machines (TBMs) to excavate and line twin 15.5-kilometre tunnels between Bella Vista and Epping. The project included the excavation and lining of five new Metro stations.

Sydney Metro Stage 2 consists of twin 15.5-kilometre tunnels from Chatswood to Marrickville, including a second harbour crossing. This will be excavated with five TBMs. The project will also see the creation of six new stations:

  • Waterloo
  • Central Station (new underground platforms)
  • Pitt Street
  • Martin Place
  • Barangaroo
  • Victoria Cross (North Sydney)
  • Crows Nest

Surex provided all underground surveying services for the excavation and lining of the tunnels and stations for both stages. This included project control (with gyro measurements), segment mould checks for the lining of the tunnel (industrial measurement), guiding the TBMs, roadheader excavation, station excavation, concrete lining & monitoring.

Two tunnel linings

Westgate Tunnel

Westgate tunnel consists of two 15.6m diameter tunnels under Yarraville, between the West Gate Freeway and the Maribyrnong River. The outbound tunnel will be 4 kilometres in length, while the inbound tunnel will be 2.8 kilometres.

Surex has been engaged to oversee the survey control and tunnelling works including maintaining the tunnel guidance systems.

The mouth of two tunnels

WestConnex

WestConnex Stage 1B, is the construction of twin tunnels extending the M4 Motorway in tunnels between Homebush and Haberfield. The tunnels were primarily excavated with Roadheaders using VMT Tunnel Guidance Systems.

Surex undertook the Survey Control for the project as well as maintained tunnel guidance systems. Surex completed the tunnel excavation and support.  The drainage and pavement works were also undertaken in the tunnel as well as services ‘fit-out’.

NorthConnex

NorthConnex is a nine-kilometre tunnel motorway, linking the M1 Pacific Motorway at Wahroonga to the Hills M2 Motorway at West Pennant Hills. When complete the project will offer the long-term capability of three lane travel in both directions.

Surex has a major role in support of tunnel works at NorthConnex completing all tunnel control, including Gyro surveys, as well as assist in tunnel excavation and maintaining tunnel guidance systems and support.

Bullimba Creek Sewer Stage 1 & 2

Bulimba Creek Sewer Upgrade Stage 2 has involved installing 4.25km of new sewer main, from Mansfield to Carindale. This included curved tunnel drives over 800m.

Bulimba Creek Stage 1 consisted of over 4.5 kilometres of sewer upgrade between Wishart and MacGregor for Queensland Urban Utilities.

Both projects used trenchless technology (pipe jacking) with both laser guidance and VMT SLS guidance systems used.
Surex was engaged for the project, with tasks including survey control, shaft works and monitoring. Surex also completed all tunnel related surveys.

Other projects

  • North-West Rail Tunnel – Sydney, NSW
  • Epping Main Sewer Project – Epping, VIC
  • Kenmore & Jindalee Cross-river Water and Sewer Pipeline – Brisbane, QLD
  • Woolloongabba Sewer Upgrade – Brisbane, QLD
  • Amaroo Main Sewer Replacement – Craigieburn, VIC
  • Moreton Bay Rail Link – QLD
  • Wynyard Walk Pedestrian Tunnel – Sydney, NSW
  • Narrows Marine Crossing Tunnel Project – Yarwun, QLD
  • Legacy Way Project – Brisbane, QLD
  • Wheatstone Project Micro-Tunnel Construction – Onslow, WA
  • North-West Rail Tunnel – Sydney, NSW
  • Epping Main Sewer Project – Epping, VIC
  • Kenmore & Jindalee Cross-river Water and Sewer Pipeline – Brisbane, QLD
  • Woolloongabba Sewer Upgrade – Brisbane, QLD
  • Amaroo Main Sewer Replacement – Craigieburn, VIC
  • Moreton Bay Rail Link – QLD
  • Wynyard Walk Pedestrian Tunnel – Sydney, NSW
  • Narrows Marine Crossing Tunnel Project – Yarwun, QLD
  • Legacy Way Project – Brisbane, QLD
